| Place of Origin | Taizhou |
| Item No. | PSG100-500 |
| Brand | Weicai |
| Model | 10-50cm |
| Place of application | Drainage system |
| Whether cross-border export exclusive source | YES |
| Material | PE |
| Specification | U80-35-500mm(with cover),U85-70-500mm,U100-45-500mm,U100-100-500mm,U100-100-1000mm new model,U100-160-1000mm new model,U150-100-1000mm,U150-150-1000mm. U160-160-1000mm,U160-160-1000mm new style,U200-160-1000mm,U200-200-1000mm,U200-200-1000mm new style,U200-350-1000mm,U200-250-1000mm,U200-250-1000mm new style,U200-250-1000mm 1000mm new,U250-250-1000mm,U250-250-1000mm new,U300-250-1000mm,U300-300-1000mm,U300-300-1000mm new,U300-300-1000mm assortment,V 300-300-1000mm, U400-400-1000mm,U400-400-1000mm new style,U450-450-1000mm,U500-500-1000mm,U500-500-1000mm new style,U250-250 assorted style |
| Model number Inside diameter specification |
Inside width (mm) |
Inside Height (mm) |
Outer width (mm) |
Outside Height (mm) |
Cover plate Width |
Matching cover size Length*Width*Height |
| U85-70-500 | 85 | 70 | 100 | 90 | 100 | 500*100*20 |
| U100-45-500 | 100 | 45 | 141 | 93 | 135 | 500*135*20 |
| U100-100-500 | 100 | 100 | 150 | 140 | 135 | 500*135*20 |
| U100-100-1000New style | 100 | 100 | 160 | 140 | 135 | 500*135*20 |
| U100-160-1000New style | 100 | 160 | 160 | 200 | 135 | 500*135*20 |
| U150-100-1000 | 150 | 100 | 230 | 140 | 200 | 500*200*20 |
| U150-150-1000 | 150 | 150 | 200 | 200 | 190 | 500*190*20 |
| U160-160-1000 | 160 | 160 | 250 | 200 | 200 | 500*200*20 |
| U160-160-1000New style | 160 | 160 | 238 | 200 | 200 | 500*200*20 |
| U200-160-1000 | 200 | 160 | 280 | 200 | 250 | 500*250*20 |
| U200-200-1000 | 200 | 200 | 280 | 240 | 250 | 500*250*20 |
| U200-200-1000New style | 200 | 200 | 255 | 232 | 250 | 500*250*20 |
| U200-350-1000 | 200 | 350 | 290 | 400 | 250 | 500*250*20 |
| U200-250-1000 | 200 | 250 | 290 | 290 | 250 | 500*250*20 |
| U200-250-1000New style | 200 | 250 | 290 | 290 | 250 | 500*250*20 |
| U250-250-1000 | 250 | 250 | 340 | 290 | 300 | 500*300*20 |
| U250-250-1000New style | 250 | 250 | 340 | 290 | 300 | 500*300*20 |
| U250-250 Latest model | 300 | 250 | 350 | 300 | 350 | 500*350*30 |
| U300-250-1000 | 300 | 300 | 400 | 360 | 350 | 500*350*30 |
| U300-300-1000 | 300 | 300 | 360 | 350 | 350 | 500*350*30 |
| U300-300-1000 Latest model | 300 | 300 | 350 | 360 | 350 | 500*350*30 |
| V type 300-300-1000 | 300 | 300 | 380 | 350 | 350 | 500*350*30 |
| U400-400-1000 | 400 | 400 | 480 | 450 | 450 | 500*450*30 |
| U400-400-1000New style | 400 | 400 | 460 | 450 | 450 | 500*450*30 |
| U450-450-1000 | 450 | 450 | 500 | 500 | 500 | 500*500*30 |
| U500-500-1000 | 500 | 500 | 580 | 550 | 550 | 500*550*30 |
| U500-500-1000New style | 500 | 500 | 580 | 550 | 550 | 500*550*30 |
Taizhou Weicai Plastic Industry Co., Ltd. is headquartered in Huangyan District, Taizhou City, Zhejiang Province, the hometown of molds in China. The company is founded on molds, with products as the priority and two-way integration. Weicai is a wholesale HDPE Plastic Linear Gap Gutter Cover company and OEM HDPE Plastic Linear Gap Gutter Cover factory, we proficient in product design, research and development, and innovation. The company has strong strength, rich production experience, and a complete sales network. The company's independently developed HDPE drainage ditches, cage supports, plastic grease traps, and reinforced three-format plastic septic tank products combine domestic and foreign technical experience to create products with performance at this stage. While producing independently, our company also undertakes the external processing business of injection molding machines ranging from 300g to 60,000g, including trial molding, proofing, processing, mold development, and joint research and development of new products.
